Horizontal Baler

    WEB - Horizontal Baler

    Efficient and reliable baling equipment

    WELL-Atech horizontal baler is a multi-functional and multi-purpose packaging equipment, the equipment adopts automatic baling technology, the baling wire
    is selected high-strength hardened iron wire, the bale is solid and not loose.The volume is greatly reduced, the density is increased, and it is convenient for transportation and storage.
    It is a powerful helper for comprehensive utilization and development of biomass energy.

    WELL-Atech WEB series Horizontal Baler, horizontal type, automatic working mode. Widely used in packing plants, carton factories, printing plants, garbage sorting and treatment stations,professional recycling stations and other places.
    It is used to compress and bundle non-metallic loose materials such as waste paper edge, carton, plastic film，PET bottles, book paper, woven bag, straw, industrial or domestic waste.

    Our product advantages

    Man machine interface, intuitive and easy to operate, automatic detection of pressure and fault；
    Decentralized cutter design and high-strength stressed beam and frame design can effectively reduce the load of the whole machine,ensure stable operation and prolong service life；
    PLC control system, touch screen control, with feed detection, automatic compression, unmanned operation.




    Chamber size and bale size can be customized according to customer requirements.
    Automatic fault diagnosis, automatic display, improve the detection efficiency.


    Automatic baling device, fast speed,low failure rate and easy to clean and maintain.
    The emergency stop button is installed independently, and the emergency stop can be carried out at any time under any state to ensure safety；
    The running process is displayed in real time on the screen to understand the working steps and processes at any time.

    Which model suits your needs?

    Specification
    		WEB-40AWEB-60A
    		WEB-80A
    		WEB-100AWEB-120A
    		WEB-150A
    Press force（tons）
    		406080100120150
    Bale size (mm)720 *7201100 * 750
    		1100 * 750
    		1100 * 1100
    		1100 * 1250
    		1100 *1250
    Motor power (kW)222237455590
    Weight（tons）
    		7912182126
    Dimension (Length)
    		6,770 mm6,880 mm6,880 mm8,560 mm9,250 mm10,050 mm
    Dimension (Width)
    		3,050 mm3,850 mm3,850 mm3,950 mm4,150 mm4,100 mm
    Dimension (Height)
    		3,580 mm3,550 mm3,550 mm4,550 mm4,850 mm4,910 mm





    • Wooden cabinet

      Output

      Mattresses

      Output

      Furniture

      Output

      Wood pallet

      Output

    • Displayer

      Output

      E-waste

      Output

      Keyboard

      Output

      PCB Boards

      Output

    • Leather

      Output

      Tires

      Output

    • Plastic

      Output

      Plastic baskets

      Output

    Can handle the following materials

    Success stories

    Mainly used for processing shredded plastic packaging containers, with a uniform discharge of about 30mm, and a movable knife that can be used on four sides
